MANUFACTURING PROCESS
Before Manufacturing : Drawings are provided to the customer before starting the manufacturing of the panel
- General Arrangement
- Single Line Diagram
- Bill Of Material
- General Notes
- Control Circuits
Testing During Inspection:
- Bill of Material Verification.
- General Arrangement Dimension check
- Function and continuity test
- Insulation Test(Magger Test)
- High Voltage Test 2.5 kV For 1 Minute.
After manufacture & testing of panel as built diagram are provided.
Technical Specification:
Rated Service Voltage | 380/415/440/690 Volt, 3 Phase, 4 Wire |
Rated Service Frequency | 50/60Hz |
Rated Service Current | Upto 8000 Amp. |
Busbar Fault Level | 25/36/50/70/100 kA Withstand (For 1sec.) |
Busbar System | TP-E or TPN-E |
Degree of Protection | IP 42-55 |
Enclosure | Indoor/Outdoor |
Type | Fixed /Draw out Type, Wall Mounted |
Busbar Support | DMC/SMC |
Cable Entry | Top/Bottom |
